PVC Jacket Oil resistance Bared Copper Stranded 3C×0.75mm2 1119103 Equivalent Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated : IEC 60332-1-2
Tensile strength:≥10.3 MPa Elongation:≥100%
Aged condition:113±1℃×168H
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758 -E258652-20060111-CertificateofCompliance-1....
| ITEM | 3C×0.75mm2 |
| CONDUCTOR | Material | Bared copper stranded |
| Size | 95/0.10mm |
| O.D.(Ref) | 1.12mm |
| INSULATION | Material | PVC |
| Min.average thickness | 0.30mm |
| Min.thickness at any point | 0.24mm |
| O.D. | 1.80±0.10mm |
| CABLING | Material | / |
| Filler | / |
| Assembly | 3C×0.75mm2 |
| JACKET | Material | PVC(Oil resistance) |
| Min.average thickness | 0.76mm |
| Min.thickness at any point | 0.61mm |
| O.D. | 5.70±0.20mm |
Insulation:PVC
Conductor : Bared copper stranded
Construction
Insulation:1~2Black with white numbers 3.green/yellow
Jacket: Per request
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International:NOUL, custom-made
RoHS,REACH Compliant,
Technical data
Rated voltage:300/500V
Rated Temperature: -40~80℃
Flame: IEC 60332-1-2
Voltage withstand test:AC 4.0kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| ELECTRICAL CHARACTERISTICS |
| 1.Voltage Rating:300/500V |
| 2.Rated temperature:-40~80℃ |
| 3.Nom. DC conductor resistance(at 20℃):27.4Ω/km |
| 4.Voltage withstand test:AC 4.0kV/1min |
| PHYSICAL PROPERTIES |
| Tensile strength:≥10.3MPa |
| Elongation:≥100% |
| Aged condition:113±1℃×168h |
| Percent of original tensile strength≥70% |
| Percent of original elongation≥65% |
| Occasional flexing: 10 x cable diameter |
| Fixed installation: 4 x cable diameter |
| Flame retardant according to IEC 60332-1-2 |
